1.65 V to 5.5 V application voltage supported on SWIM interface.USB 2.0 full-speed-compatible interface.

With cover case for protection, anti-dust and anti-short circuit.Specifically the debugger incorporates the use of USB full-speed interface to communicate with the ST Visual Develop (STVD) or ST Visual Program (STVP) software for STM8 application, and use of the USB full-speed interface to communicate with Atollic ®, IAR ™, Keil® or TASKING integrated development environments for STM32 applications. Much similar in architecture for debugging, the ST-LINK/V2 and the ST-LINK/V2-ISOL share the same features like digital isolation between the PC and the target application board this allows to withstands voltages of up to 1000 Vrms.

The single wire interface module (SWIM) and JTAG/serial wire debugging (SWD) interfaces are used to communicate with any STM8 or STM32 microcontroller located on an application board.

JTAG cable for connection to a standard JTAG 20-pin pitch 2.T he ST-LINK/V2 In-Circuit Debugger/Programmer For STM8 And STM3 is an in-circuit debugger and programmer for the STM8 and STM32 microcontroller families.

1.65 V to 3.6 V application voltage supported on the JTAG/SWD interface and 5 V tolerant inputs.

JTAG/serial wire debugging (SWD) specific features:.

SWIM cable for connection to the application via a pin header or a 2.54 mm pitch connector.

SWIM cable for connection to the application via an ERNI standard vertical connector (ref: 284697 or 214017) or horizontal connector (ref: 214012).

SWIM programming speed rate: 9.7 Kbytes/s in low speed and 12.8 Kbytes/s in high speed.

SWIM low-speed and high-speed modes supported.

With cover case for protection, anti-dust and anti-short circuit.Specifically the debugger incorporates the use of USB full-speed interface to communicate with the ST Visual Develop (STVD) or ST Visual Program (STVP) software for STM8 application, and use of the USB full-speed interface to communicate with Atollic®, IAR™, Keil®or TASKING integrated development environments for STM32 applications. The ST-LINK/V2 is an in-circuit debugger and programmer for the STM8 and STM32 microcontroller families.
